| Brand Name : | QY |
| Model Number : | q195/235 |
| Price : | contact with me for update |
| Payment Terms : | T/T, Western Union |
| Supply Ability : | 20tons/day |
| Delivery Time : | 10days |
Features: Black wire is rust proof within 6 months without any oil coating. The tensile strength is 300-400 Newton per square millimeter.
Wire sizes: Wire diameter ranges from 0.70mm to 40mm.
Forms of Supply: Straightened cut wire, U type wire, coil wire, etc.
Application: Black annealed wire is mainly used as industrial wire, construction wire, industrial bale tie wire and constructional tie wire, etc.
Packing: Different coil diameter or coil weight available for customers’ choice.
Specification list
| Black Wire | |||
| Gauge | SWG(mm ) | BWG(mm) | In Metric system mm |
| 8# | 4.06 | 4.19 | 4.00 |
| 9# | 3.66 | 3.76 | 3.80 |
| 10 # | 3.25 | 3.40 | 3.50 |
| 11 # | 2.95 | 3.05 | 3.00 |
| 12 # | 2.64 | 2.77 | 2.80 |
| 13 # | 2.34 | 2.41 | 2.50 |
| 14 # | 2.03 | 2.11 | 2.10 |
| 15 # | 1.83 | 1.83 | 1.80 |
| 16 # | 1.63 | 1.65 | 1.65 |
| 17 # | 1.42 | 1.47 | 1.40 |
| 18 # | 1.22 | 1.25 | 1.20 |
| 19 # | 1.02 | 1.07 | 1.00 |
| 20 # | 0.91 | 0.89 | 0.90 |
| 21 # | 0.81 | 0.813 | 0.80 |
| 22 # | 0.71 | 0.711 | 0.7 |
Products Information
| Material: | Low carbon steel wire |
| Wire Diameter: | 0.265 ~ 1.8mm |
| Tensile Strength: | 300 ~ 500MPa. |
| Rate of Extend: | 15% |
| Packing | Spool, coil |
| Soft Black Annealed Wire | ||||
| Wire Diameter | Strength | Packing | Weight | Application |
| 0.16mm-0.6mm | 30-40kg | Coils or spools | 2-100kgs | Binding wire for Christmas trees |
| 0.6mm-5.0mm | 30-40kg | Big package | 100-800kgs | |
| 0.16mm-0.6mm | 60-70kg | Coils or spools | 2-100kgs | |
| 0.6mm-5.0mm | 60-70kg | Big package | 100-800kgs | |
